deye micro on-grid solar inverter 600w 800w 1000w with 10 years warranty 212W*230H*40D

20 pieces
MOQ
deye micro on-grid solar inverter 600w 800w 1000w with 10 years warranty 212W*230H*40D
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Model Number: SUN600G3-EU-230
Input Voltage: 60v
Output Voltage: 220/230v
Output Current: 13A
Output Frequency: 50/60HZ
Output Type: Single
Size: 212W*230H*40D
Type: DC/AC Inverters
Inverter Efficiency: 99%
Certificate: CE/ICE/VDE
Warranty: 10years, 10 years
Weight: 3.15kg
MPPT Voltage Range: 25~55V
Max. input Current: 2*13A
No.of MPP Trackers: 2
Rated output Power: 600W
Maximum units per branch: 8
Enclosure Environmental Rating: IP67
Basis informatie
Certificering: CE/ICE/VDE
Model Number: SUN600G3-EU-230
Betalen & Verzenden Algemene voorwaarden
Packaging Details: 31pcs/pallet, 682pcs/40HQ
Supply Ability: 1000000000 Piece/Pieces per Week
Productomschrijving
Products Description
Product Paramenters
Model
SUN600G3-EU-230
Input Data(DC)
Recommended input power(STC)
210-400W(2 Pieces)
Maximum input DC voltage(V)
60V
MPPT voltage range(V)
25-55V
Full load DC voltage range(V)
24.5-55V
Max.DC short circuit current(A)
2x19.5A
Max.input current(A)
2x13A
No.of MPPT trackers
2
No.of Strings per MPP Tracker
1
Output Data(AC)
Rated output power
600W
Rated output current
2.6A
Nominal voltage/range(this may vary with grid standards)
230V/0.85Un-1.1Un
Nominal frequency/range
50/60Hz
Extended frequency/range
45-55Hz/55-65Hz
Power factor
﹥0.99
Maximum units per branch
8
Efficiency
CEC Weighted Efficiency
95.00%
Perk Inverter Efficiency
96.50%
Static MPPT Efficiency
99.00%
Night Time Power Consumption
50mW
Mechanical Data
Ambient Temperature Range
-40℃-65℃
Size(mm)
212Wx230Hx40D(Without mounting bracket and cable)
Weight(kg)
3.15kg
Cooling
Natural cooling
Enclosure Environmental Rating
IP67
Features
Compatibility
Compatible with 60-72 cell PV modules
Communication
Power line/WIFI/Zigbee
Grid Connection Standard
EN50549-1,VDE0126-1-1,VDE4105,ABNT NBR 16149,ABNT NBR 16150,ABNT NBR 62116,RD 1699,UNE 206006 IN,UNE 206007-1 IN,IEEE1547
Safety EMC/Standard
UL 1741,IEC62109-1/-2,IEC61000-6-1,IEC61000-6-3,IEC61000-3-2,IEC61000-3-3
Warranty
10 years
