Maximum Power | Pmax[W] | 440 | 445 | 450 | 455 | 460 | 465 | 470 | 475 | ||||||
Maximum Power Voltage | Vmp(V) | 41.40 | 41.75 | 42.10 | 42.41 | 42.76 | 43.10 | 43.44 | 43.78 | ||||||
Maximum Power Current | Imp(A) | 10.63 | 10.66 | 10.69 | 10.73 | 10.76 | 10.79 | 10.82 | 10.85 | ||||||
Open Circuit Voltage | Voc(V) | 49.25 | 49.55 | 49.84 | 50.10 | 50.39 | 50.68 | 50.96 | 51.25 | ||||||
Short Circuit Current | Isc(A) | 11.28 | 11.31 | 11.34 | 11.37 | 11.40 | 11.43 | 11.47 | 11.50 | ||||||
Module Efficiency | (%) | 20.2 | 20.5 | 20.7 | 20.9 | 21.2 | 21.4 | 21.6 | 21.9 | ||||||
Power Output Tolerance | (W) | 0~+5 Irradiance 1000W/m2. Cell Temperature 25..Air Mass 1.5 |
Number of Cells | 144 Cells (x24) | Nominal Module Operating Temperature(MOT) | 43 ± 2°C |
Dimensions of Module L*W*H (mm) | 2094x1038 x35mm | Temperature Coefficient of Isc | +0.05%/P |
Weight (g) | 23 kg. | Temperature Coefficient of Voc | -0.28%/t) |
Glass | High transparency solar glass 3.2mm(0.13 inches) | Temperature Coefficient of PMAX | -0.36%/°C |
Backsheet | White | Operational Temperature | 40~+85*C |
Frame | Silver, anodized aluminium alloy | Maximum System Voltage | 1500V DC |
J-Box | IP68 Rated | Max Series Fuse Rating | 20A |
Cable | 4.0mm2 [0.006 inches2), Portrait: 280/280mm (11.02inches, | Module per box | 36 pieces |
Number of diodes | 3 | Module per 40 container | 720 pieces |
Wind/ Snow Load | 2400Pa/ 3600Pa* | ||
Connector | MC 4Compatible |
Maximum Power | Pmax(W) | 525 | 530 | 535 | 540 | 545 | 550 | 555 | 560 | |||||||
Maximum Power Voltage | Vmp(V) | 41.21 | 41.48 | 41.77 | 42.06 | 42.35 | 42.64 | 42.93 | 43.22 | |||||||
Maximum Power Current | Imp(A) | 12.74 | 12.78 | 12.81 | 12.84 | 12.87 | 12.90 | 12.93 | 12.96 | |||||||
Open Circuit Voltage | Voc(V) | 49.05 | 49.28 | 49.51 | 49.75 | 49.98 | 50.22 | 50.45 | 50.68 | |||||||
Short Circuit Current | Isc(A) | 13.53 | 13.57 | 13.60 | 13.63 | 13.66 | 13.70 | 13.73 | 13.76 | |||||||
Module Efficiency | (%) | 20.3 | 20.5 | 20.7 | 20.9 | 21.1 | 21.3 | 21.5 | 21.7 | |||||||
Power Output Tolerance | (W) | 0~+5 |
Number of Cells | 144 Cells (x24) | Nominal Module Operating Temperature(MOT) | 43 ± 2°C |
Dimensions of Module L*W*H (mm) | 2278x1134x30 mm (9 .69x44.65x1.18 inches) | Temperature Coefficient of Isc | +0.05%/P |
Weight (g) | 26.8 kg. | Temperature Coefficient of Voc | -0.28%/t) |
Glass | High transparency solar glass 3.2mm(0.13 inches) | Temperature Coefficient of PMAX | -0.36%/°C |
Backsheet | White | Operational Temperature 一 | 40~+85*C |
Frame | Silver, anodized aluminium alloy | Maximum System Voltage | 1500V DC |
J-Box | IP68 Rated | Max Series Fuse Rating | 20A |
Cable | 4.0mm2 [0.006 inches2), Portrait: 280/280mm (11.02inches, | Module per box | 36 pieces |
Number of diodes | 3 | Module per 40 container | 720 pieces |
Wind/ Snow Load | 2400Pa/ 5400Pa* | ||
Connector | MC 4Compatible |
